Piston pump (grease) - 2 Kg - 230V - with control unit
The model PG203 is a versatile, compact and economical lubrication pump that can supply up to 150 lubrication points depending on the line length. It consists of a housing with integrated motor, a container with agitator blade, a pump element, a filling nipple and electrical connection parts. This powerful pump can drive up to three pump elements and can be equipped with level monitoring (with or without control board).
Features and benefits:
- Various container types to choose from
- For direct current (12V / 24V) and alternating current (110-260 V AC) applications
- Optional pressure relief valve
- Choice of pump elements for different flow rates
Applications
- Mobile applications
- Wheel loader, excavator
- Small to medium machines
- General industrial applications
- Combine harvesters, balers, choppers
Technical design:
- container size: 2 kg plastic container, with stirrer blade
- Container designs: 1 kg without screw cap
- Pump elements: 2 piece K6 = 2.8 cm³/min, alternatively K7 = 4.0 cm³/min
- Empty signal: Level monitoring available
- Pressure relief valve; 1 piece with 350 bar for connection Ø 6 mm
- Control: available, lubrication time and pause time infinitely adjustable. Monitoring time adjustable when using a piston detector on the progressive distributor
- Electrical connection: Power supply 24V DC via cube plug
Level monitoring integrated in control unit - Filling: via existing grease nipple
- Operating voltage: 230 V AC
Dimension:
